Specifications
|
| Model: |
IPC RK4380G |
| Dimensions: |
(W × H × D) 19" x 4U × 380mm (14.96" deep) |
| Cooling: |
1 × brand new Sunon EEC0251B1-000C-G99 120mm × 25mm 2ball bearing intake fan |
| Power Supply: |
Support PS2 power supply (max. psu depth:200mm)
Or support PS2 Mini Redundant power supply |
| Expansion: |
Support 7 slot full high expansion cards (max. 175mm long) |
| Controls: |
Power on/off, system reset and 2 × USB ports |
| System Board: |
ATX 12" × 9.6" and 9.6" × 9.6" MicroATX and 6.7" × 6.7" Mini-ITX MB |
| Drive Bay: |
3 x 5.25" DVD and 8 × 3.5" HDD and 1 × 2.5" HDD bay |
| Package: |
NW 7.3 KGM, GW 9.3 KGM, 2.78 CUFT (carton size: 560 × 530 × 265mm) |
| Mounting Options: |
CLM-882054B: 20" Slinding Rails + Bracket
CLM-882054B-26: 26" Slinding Rails + Bracket
GNS-1234RMK: 1234U rear mounting kit, 300mm depth |
| Backplane Module Options |
SNT-1041SS: 4×2.5" SAS & SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-1060SATA: 6×2.5" SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-2131SS: 3×2.5/3.5" SAS & SATA HDD/SSD in 2×5.25" Bay, hot swappable.
SNT-3141SS: 4×2.5/3.5" SAS & SATA HDD/SSD in 3×5.25" Bay, hot swappable.
SNT-3051SS: 5×2.5/3.5" SAS & SATA HDD/SSD in 3×5.25" Bay, hot swappable. |
| Other Information: |
Intelligent EnergySaving device's default is all fans automatically activated if system temperature up to 38 degree-C
Intelligent EnergySaving device's default is 38 degree-C but individual fan can be adjusted between 30~60 degree-C
Intelligent EnergySaving device supported with four fan fail's indication and warming (stop warning by any button)
Intelligent EnergySaving device supported with Celsius or Fahrenheit Degree (convertible by C/F button)
Build in high grade aluminum rackmounting handles
Build in removable front cover with air filter |
