*Click to see the enlarged view. |
| Features |
- Hot swappable
- Air-ventilaiton holes for best heat sink
- Support SATA- I,II,III
- Super Cooling fan : 2 × 40mm fan
- All aluminum material solid contruction
- Support 2.5” HDD thickness upto 9.5 mm
- High performance transfer rate up to 6G
|
Specifications
|
| Model |
SNT-1060SATA |
| Color |
Black |
| HDD |
Support 6 × 2.5" SATA HDD
Support 9mm thickness HDD |
| Application |
5.25" form factor drive space |
| Interface |
Support SATA I,II, III |
| Transfer Connector |
7-pin SATA port connector |
| Transfer Rate |
6Gbps |
| Material |
Aluminum |
| LED Display |
Power & HDD accessing status |
| Switch Design |
Mechanical latch switch design |
| Power |
1 × standard 4-pin connector |
| Dimension |
172(L) × 146(W) × 42(H)mm |
| Weight |
1.3 kg |
