Specifications
|
| Model: |
IPC C2T-3 PCI |
| Industry Standard |
EIA-RS310D |
| Materials |
Heavy-duty preplated SPGC cold-rolled steel |
| Finish |
Front Panel : Texture-coated |
Dimension
(W × D × H) |
mm: 482.6 × 530 × 88.8
inches: 19 × 20.9 × 3.5 |
| Cooling |
Middle : 2 × 80 × 25mm fans
Rear : 1 × 80 × 25mm fan |
| Power Supply |
Standard PS/2 PSU |
| Expansion |
3 × PCI Full height slots via Riser Card |
| Controls |
Power on/off, system reset and 2 × USB ports |
| Indicators |
Power, 2 × LAN and HDD LEDs |
| System Board |
Up to 12”(W) × 10.5”(D) ATX/SSI CEB compliant MB |
| Drive Bay |
External: 1 × 5.25"
Internal: 4 × 3.5" HDD |
| Temperature |
0°C (32°F)~50°C (122°F) |
| Humidity |
5%~95% non-condensing |
| Gross Weight |
11.5kgs / 25.3lbs (w/o PSU & Rail) |
| Package Dimension |
(W × D × H) mm: 590 × 725 × 292 |
| Riser Card Options |
Riser Cards |
| Mounting Options |
CLM-882054B: 20" Sliding Rails + Brackets
CLM-882054B-26: 26" Sliding Rails + Brackets |
| Backplane Module Options |
SNT-1041SS: 4×2.5" SAS & SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-1060SATA: 6×2.5" SATA HDD/SSD in 1×5.25" Bay, hot swappable. |
