Specifications
|
| Model: |
IPC-C4EH |
| Industry Standard: |
EIA-RS310D |
| Materials: |
Heavy-duty preplated SPGC cold-rolled steel |
| Finish: |
Front Panel : Texture coated |
Dimensions:
(W × D × H) |
mm: 483 × 679 × 173.5 |
| inches: 19 × 26.7 × 7 |
| Cooling: |
Middle: 3 × 120 × 38mm easy-swap fans |
| Rear: 2 × 60 × 38mm fans (optional) |
| Power Supply: |
1010W 1+1 hot-swap redundant |
| Expansion: |
7 × PCI slots (full height, full length) |
| Controls: |
Power on/off and system reset |
| Indicators: |
Power, 2 × LAN and HDD LEDs |
| System Board: |
12”(W) × 13”(D) E-ATX/SSI EEB 3.6 compliant MB |
| Drive Bay: |
External |
3.5" hot-swap |
24 |
| 2.5" hot-swap |
Options:
2 × 2.5” hot-swap,
1 × 3.5” internal, or
2 × 2.5” internal |
| Internal |
3.5" HDD |
| 2.5" HDD |
| Temperature: |
0°C (32°F)~50°C (122°F) |
| Humidity: |
5%~95% non-condensing |
| Gross Weight: |
35 kgs / 77 lbs (w/ PSU & Rail) |
| Package Dimension: |
(W × D × H): mm: 610 × 920 × 380 |
| Mounting Options: |
28" inner rail, 26" outer rail, tool-less |
| More Information: |
IPC C4EH Datasheet |
