Specifications
|
| Model: |
IPC-C3K |
| Industry Standard: |
EIA-RS310D |
| Materials: |
Heavy-duty cold-rolled steel |
| Finish: |
Outside / Front Panel : Black |
Dimensions:
(W × D × H) |
mm: 482.6 × 685.8 × 133.4 |
| inches: 19 × 27 × 5.25 |
| Cooling: |
Middle: 2 × 40 × 25mm + 3 × 80x32mmfans |
| Rear: 2 × 60 × 25mm hot-swap fans(optional: Upgrade to 60 × 38mm) |
| Power Supply: |
650W high efficiency 2+1 hot-swap redundant PFC |
| Expansion: |
7 × PCI slots (full height) |
| Controls: |
Power on/off, system reset, and dual USB2.0 |
| Indicators: |
Power, LAN and HDD LEDs |
| System Board: |
12"(W) × 13 "(D) E-ATX/SSI EEB 3.5 compliant motherboard |
| Drive Bay: |
12 × hotswap + 1 × Slim CD + 1 × 5.25" + 1 × 3.5" |
| Temperature: |
0°C (32°F)~50°C (122°F) |
| Humidity: |
5%~95% non-condensing |
| Mounting Options: |
26" Sliding Rails + Brackets |
