| Dimensions (W x D x H) (with chassis ears) |
• mm : 483 x 645 x 88
• inches : 19 x 25.4 x 3.5 |
| Industry Standard |
| EIA-RS310D |
| Material |
| Heavy-duty preplated SPGC cold-rolled steel |
| Color |
| Front Panel : Black |
| Cooling |
| Middle : 3 x 80x38mm PWM & low-power consumption hot swap fans |
| Power Supply |
| 800W 1+1 redundant PSU PMBus 1.2 80+ Gold |
| Expansion Slots |
| 7 low profile |
| Front Panel |
• Power on/off
• System reset
• 1 x USB 3.0 port |
| LED Indicators |
• Power
• LAN
• Drive
• Alert |
| System Board |
| 12”(W) x 13”(D) E-ATX/SSI EEB 3.6 compliant MB |
| Drive Bays |
• External : 12 x 3.5” hot swap
Choose 1 :
• External : 2 x 2.5” hot swap with 1U PSU
• Internal : 2 x 2.5” with 2U PSU |
| Backplane |
| 1 x 12-port 12Gb SAS backplane with 28-PHY expander and 3 SFF-8643 connectors |
| Storage Temperature |
| 0°C(32°F) ~ 50°C(122°F) |
| Humidity |
| 5% ~ 95% non-condensing |
| Gross Weight (w/ PSU & Rail) |
• kgs : 27
• lbs : 59.5 |
| Package Dimension (W x D x H) |
• mm : 590 x 850 x 270
• inches : 23.2 x 33.5 x 10.6 |
| Cubic Feet |
| 4.65 |
| Container Load Quantity |
• 20’ : 205
• 40’ : 420
• 40’ H : 505 |
| Mounting |
| Standard : 28” tool-less slide rail |
