Specifications
|
| Model: |
RMC-2A |
| Industry Standard |
EIA-RS310D |
| Materials |
Heavy-duty cold-rolled steel |
| Color |
Inside / Body: Zinc-plated with bright chromate
Outside / Front Panel : Black |
Dimension
(W × D × H) |
mm: 482.6 × 431.8 × 88.8
inches: 19 × 17 × 3.5 |
| Cooling |
Middle : 2 × 80x25mm fans
Rear : 1 × 97mm blower |
| Power Supply |
300W / 400W single PSU |
| Expansion |
3 × PCI slots via riser card (full height) or
7 × low profile PCI slots |
| Controls |
Power on/off, system reset and 2 × USB ports |
| Indicators |
Power, LAN and HDD LEDs |
| System Board |
Up to 12”(W) × 9.6”(D) ATX compliant MB |
| Drive Bay |
External |
5.25" |
1 |
| 3.5" |
1 |
| Internal |
3.5" HDD |
3 |
| Peripheral Drives |
Slim DVD-Rom |
1 |
| Temperature |
0°C (32°F)~50°C (122°F) |
| Humidity |
5%~95% non-condensing |
| Gross Weight |
12.7kgs / 27.9lbs (w/ PSU; w/o Rail) |
| Package Dimension |
(W × D × H) mm: 576 × 591 × 233 |
| Mounting Options |
CLM-882054B: 20" Sliding Rails + Brackets
CLM-882054B-26: 26" Sliding Rails + Brackets |
| Backplane Module Options |
SNT-1041SS: 4×2.5" SAS & SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-1060SATA: 6×2.5" SATA HDD/SSD in 1×5.25" Bay, hot swappable. |
