| Model No |
IPC-C2T-SB |
| Color |
Front Panel : Black |
Dimensions
(W × D × H) |
mm: 482.6 × 530 × 88.8
inches: 19 × 20.9 × 3.5 |
| Cooling |
Middle : 2 × 80x25mm fans
Rear : 1 × 80x25mm fan |
| Power Supply |
Standard PS/2 PSU |
| Expansion |
3 × PCI slots via riser card (full height, full length) |
| Controls |
Power on/off, system reset and 2 × USB ports |
| Indicators |
Power, 2x LAN and HDD LEDs |
| Drive Bay |
External: 1 × 5.25"
Internal: 4 × 3.5" HDD |
| Chipset |
Socket B2 LGA-1356 |
| Integrated Systems Available |
Yes |
| Integrated BMC with IPMI |
IPMI 2.0 |
| Rack-Friendly Board |
Yes |
| Max TDP |
95 W |
Memory |
| Max Memory Size (dependent on memory type) |
96 GB |
| Memory Types |
DDR3/LV DDR3 ECC UDIMM 1066/1333, RDIMM/LV RDIMM 1066/1333/1600 (no LRDIMM, QRDIMM) |
| # of Memory Channels |
3 |
| Max Memory Bandwidth |
307.2 GB/s |
| Physical Address Extensions |
46-bit |
| # of DIMMs |
6 |
| ECC Memory Supported |
Yes |
|
Expansion Slots |
| PCI Support |
yes |
| PCI Express Revision |
3 |
| PCIe x4 Gen 3 |
1 |
| PCIe x8 Gen 3 |
1 |
| PCIe x16 Gen 3 |
1 |
| PCIe x4 Gen 2.x |
1 |
|
Graphics |
| Integrated Graphics |
Yes |
| Graphics Output |
D-sub |
| Discrete Graphics |
Supported |
|
I/O |
| USB 2.0 Configuration (Back + Internal) |
6 |
| RAID Configuration |
SW Raid 0/1/10/5 (LSI + RSTE) |
| # of Serial Ports |
2 |
| # of LAN Ports |
2 |
| Integrated LAN |
2x 1GbE |
| Embedded USB (eUSB) Solid State Drive Option |
Yes |
| Integrated SAS Ports |
8 |
|
