| Model No |
IPC-C1E-SB |
| Materials |
Heavy-duty SPGC preplated cold-rolled steel |
| Color |
Front Panel : Black |
Dimensions
(W × D × H) |
mm: 482.6 × 381 × 44.4
inches: 19 × 15 × 1.75 |
| Cooling |
Front : 1 × 97mm blower |
| Power Supply |
250W single PSU
300W single PSU 80+ |
| Expansion |
1 × PCI slot via riser card (full height, half length) |
| Controls |
Power on/off, system reset, and 2 × USB ports |
| Indicators |
Power, 2 × LAN, and HDD LEDs |
| Drive Bay |
Internal: 2 × 3.5" HDD
Peripheral Drives: 1 × Slim DVD-Rom |
| Chipset |
Socket B2 LGA-1356 |
| Integrated Systems Available |
Yes |
| Integrated BMC with IPMI |
IPMI 2.0 |
| Rack-Friendly Board |
Yes |
| Max TDP |
95 W |
| Memory |
| Max Memory Size (dependent on memory type) |
96 GB |
| Memory Types |
DDR3/LV DDR3 ECC UDIMM 1066/1333, RDIMM/LV RDIMM 1066/1333/1600 (no LRDIMM, QRDIMM) |
| # of Memory Channels |
3 |
| Max Memory Bandwidth |
307.2 GB/s |
| Physical Address Extensions |
46-bit |
| # of DIMMs |
6 |
| ECC Memory Supported |
Yes |
|
Expansion Slots |
| PCI Support |
yes |
| PCI Express Revision |
3 |
| PCIe x4 Gen 3 |
1 |
| PCIe x8 Gen 3 |
1 |
| PCIe x16 Gen 3 |
1 |
| PCIe x4 Gen 2.x |
1 |
|
Graphics |
| Integrated Graphics |
Yes |
| Graphics Output |
D-sub |
| Discrete Graphics |
Supported |
|
I/O |
| USB 2.0 Configuration (Back + Internal) |
6 |
| RAID Configuration |
SW Raid 0/1/10/5 (LSI + RSTE) |
| # of Serial Ports |
2 |
| # of LAN Ports |
2 |
| Integrated LAN |
2x 1GbE |
| Embedded USB (eUSB) Solid State Drive Option |
Yes |
| Integrated SAS Ports |
8 |
|
