Specifications
|
| Model: |
IPC RK3380G |
| Dimensions: |
(W × D × H) 19" × 380 × 3U mm (14.96" deep) |
| Cooling: |
1 × brand new Sunon EEC0251B1-000C-G99 120mm × 25mm 2ball bearing intake fan |
| Power Supply: |
Support PS2 power supply |
| Expansion: |
If front fixed with 3.5" HDD, 4 slot full high plugin cards compatible (maximum card depth at 170mm)
If front w/o 3.5" HDD & bracket installed, 4 slot full high plugin cards compatible (maximum card depth at 330mm) |
| Controls: |
Power on/off, system reset and 2 × USB ports |
| System Board: |
ATX 12" × 9.6" and 9.6" × 9.6" MicroATX and 6.7" × 6.7" Mini-ITX MB |
| Drive Bay: |
Two 5.25" ODD and five 3.5" HDD bay (12" × 9.6" ATX MB installed mode)
or three 5.25" ODD and five 3.5" HDD bay (9.6" × 9.6" MicroATX MB installed mode)
or two 5.25" ODD and six 3.5" HDD bay (9.6" × 9.6" MicroATX MB installed mode)
or two 5.25" ODD and five 3.5" HDD and two 2.5" SSD/HDD bay (9.6" × 9.6" MicroATX MB installed mode) |
| Package: |
NW 6.2 KGM, GW 8.2 KGM, 2.22 CUFT (carton size: 560 × 510 × 220mm) |
| Mounting Options: |
CLM-882054B: 20" Slinding Rails + Bracket
CLM-882054B-26: 26" Slinding Rails + Bracket
GNS-1234RMK: 1234U rear mounting kit, 300mm depth |
| Backplane Module Options |
SNT-1041SS: 4×2.5" SAS & SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-1060SATA: 6×2.5" SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-2131SS: 3×2.5/3.5" SAS & SATA HDD/SSD in 2×5.25" Bay, hot swappable.
SNT-3141SS: 4×2.5/3.5" SAS & SATA HDD/SSD in 3×5.25" Bay, hot swappable.
SNT-3051SS: 5×2.5/3.5" SAS & SATA HDD/SSD in 3×5.25" Bay, hot swappable. |
| Other Information: |
If 140mm deep PS2 psu installed, 5.25" ODD device by maximum 210mm depth is also compatible
If 180mm deep PS2 psu installed, 5.25" ODD device by maximum 170mm depth is also compatible |
