| Dimension |
19'' × 2U × 380mm (14.96" deep) |
| Cooling |
2 × Sunon 80mm × 25mm intake fans with air filter at front bezel |
| Power Supply |
PS2 power supply (8cm fan version) |
| Expansion |
4 × Low Profile expansion cards (max. 170mm deep if HDD installed, 330mm deep if HDD not installed) |
| Controls |
Power on/off, system reset and 2 × USB ports |
| System Board |
9.6" × 9.6" Micro-ATX MB, 6.7" × 6.7" Mini-ITX MB |
| Drive Bay |
2 × 5.25" DVD bay, 2 × 3.5" HDD bay
or 1 × 5.25" DVD bay, 2 × 2.5" HDD bay, 2 × 3.5" HDD bay
or 1 × 5.25" DVD bay, 3 × 3.5" HDD bay |
| Package |
NW 5 KGM, GW 6.5 KGM, 1.75 CUFT (56.5x51.5x17cm, single box packed) |
| Mounting Options |
CLM-882054B: 20" Slinding Rails + Bracket
CLM-882054B-26: 26" Slinding Rails + Bracket
GNS-1234RMK: 1234U rear mounting kit, 300mm depth |
| Backplane Module Options |
SNT-1041SS: 4×2.5" SAS & SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-1060SATA: 6×2.5" SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-2131SS: 3×2.5/3.5" SAS & SATA HDD/SSD in 2×5.25" Bay, hot swappable. |
| Other Information |
If 140mm deep PS2 psu installed, max. 210mm deep 5.25" ODD device compatible
If 180mm deep PS2 psu installed, max. 170mm deep 5.25" ODD device compatible |
