| Dimension |
19" × 1U × 250mm (9.84" deep) |
| Cooling |
2 × Adda AD0412HB-C56 40mm × 20mm intake fans behind the front bezel |
| Power Supply |
Standard 1U FlexATX 150W~250W psu (max. psu depth: 150mm) |
| Controls |
Power on/off, system reset and 2 × USB ports |
| System Board |
6.7" × 6.7" standard Mini-ITX MB (170mm × 170mm) |
| Drive Bay |
2 × 2.5" HDD or 1 × 3.5" HDD/FDD (or optional 2 × 2.5" hotswap HDD) |
| Package |
NW 3.5 KG, GW 4.5 KG, 1.00 CUFT (55.5 × 37.5 × 13.5cm, single box packed) |
| Backplane Module Options |
SNT-2221SUSRI SATA
SNT-2223 SATA |
| CPU Cooler Options |
1U CPU Coolers |
