-Ultra Slim Design
-With 9 diferent notebook connectors
-USB Port
| Output Power: |
90W(Max) |
| Efficiency: |
>80%(TYP) |
| Input Votage: |
AC 100-240V |
| Input Current: |
1.5A |
| Output voltage: |
DC12 - DC20V |
| USB Port: |
5V / 1.0A |
| Output Current: |
12V - 4.5A
15V - 4.5A
16V - 4.5A
18V - 4.5A
18.5V - 4.5A
19V - 4.5A
19.5V - 4.5A
20V - 4.5A |
| Protection: |
Overload, Short circuit, Overhearint |
| Dimension: |
144 (L) × 75 (W) × 18.5 (H) mm |
|
Pin Head Tips:
6.0x1.0mm Black (Fujitsu siemens, Sony)
5.5x2.5mm White (Compaq, Acer, Dell)
6.3x3.0mm Green (Fujitsu siemens, Toshiba)
5.5x2.1mm Blue (Acer)
5.5x1.7mm Yellow (Acer, Compaq)
4.8x1.7mm Yellow (HP, Asus, NEC)
4.0x1.7mm Yellow (LCD Display)
5.0x1.0mm Yellow (Samsung)
7.4x5.0mm Yellow (HP) |
