Input：
★Input voltage: 100 - 240Vac Full Range.
★Frequency: 50 - 60Hz.
★Input Current: 12A for 115VAC,  6A for 230VAC.
★Inrush Current: 30A for 115VAC, 60A for 230VAC.
★The Minimum efficiency of the power supply is 80% at full load and 115Vac/60Hz input.
★The minimum power factor at full load shall be 0.98 / 115V 60 Hz and 0.96 / 230V 50 H

Output Voltage	+5V DC	+12V DC	+3.3V DC	-12V DC	+5VSB
Output Current(Max)	32A	57A	32A	0.8A	3.5A
Output Current(Min.)	1A	1A	1A	0A	0.5A
Ripple/Noise Max.(P-P):	60mv	120mv	60mv	120mv	50mV
Line Regulation:	±1﹪	±1﹪	±1﹪	±1﹪	±1﹪
Load Regulation:	±5﹪	±5﹪	±5﹪	±5﹪	±5﹪

The combined total power from 5V & 3.3V shall not exceed 190W.

◎ FEATURES:
★Meet the RoHS COMPLIANT 2011/65/EU

★Temperature  Range: Operating 0℃  ~ 50℃ , Storage –20℃  ~  70℃

★Hold up time: 16 ms Minimum at full load & Normal input voltage.

★OVER POWER PROTECTION: 110~150%
★OVER VOLTAGE PROTECTION

★OVER CURRENT PROTECTION

★SHORT CIRCUIT PROTECTION

★Remote On/Off Control.

★Power Good Signal: On Delay 100ms to 500ms, off delay 1ms.

★Safety: To meet UL, TUV, CB, CE, FCC, BSMI, CCC.

★EMI noise Filter: FCC Class B, CISPR22 Class B

★Altitude during operation: Up to 5000m



Connectors：
