| LCD Panel |
- 15" XGA TFT LCD
- 420 nits
- 1024 x 768 pixels
|
| CPU |
- Intel® Core™ i5-7300U 3.5 GHz (Kaby Lake)
|
| Chipset |
|
| System Memory |
- 1 x 260-pin SO-DIMM DDR4-2133, up to 16GB
|
| BIOS |
|
| COM |
- 2 x RS-232/422/485 (default RS-232, A-coded)
|
| USB |
|
| Ethernet |
- 1 x 10/100/1000 Mbps (Intel® I210-IT; X-coded)
|
| Display |
|
| Audio |
|
| Storage |
- 1 x 2.5" SSD HDD or 1 x 2.5" SATA HDD
|
| Expansion |
- 1 x Full-size PCI Express Mini Card slot
- 1 x Half-size PCI Express Mini Card slot
|
| Others |
- 1 x 2.5" SSD HDD or 1 x 2.5" SATA HDD
|
| Touchscreen |
- 5-wire resistive touch or projected capacitive multi-touch
|
| Front Bezel |
|
| Power Supply |
|
| Power Comsumption |
|
| Watchdog Timer |
|
| Operating Temperature |
- -20°C ~ +50°C (-4°F ~ +122°F)
|
| Relative Humidity |
- 10% ~ 95% @ 40°C, non-condensing
|
| Vibration |
- 1G, 5 ~ 500Hz, random for 2.5" SSD
|
| Dimensions (W x D x H) |
- 382 x 55 x 305 mm (15.4" x 2.17" x 12.01")
|
| Weight (net/gross) |
- 5.2 kg (11.46 lb)/8.4 kg (18.5 1b)
|
| Certifications |
|
| EOS |
- Windows® 10 IoT, Windows® 10
|
| Mounting |
|
