Specifications
|
| Model: |
IPC C2N |
| Dimensions: |
(W × D × H) 19" × 2U × 575.4mm (22.7 inch deep) |
| Cooling: |
2 × 80mm + 1 × 40mm fans |
| Power Supply: |
400W single PSU
510W single PSU
500W 1+1 hot-swap redundant PFC
600W 1+1 hot-swap redundant PFC |
| Expansion: |
3 × PCI slots via riser card (full height) or 7 × low profile PCI slots |
| Controls: |
Power on/off, system reset and 2 × USB ports |
| Indicators: |
Power, LAN, and HDD LEDs |
| System Board: |
Up to 12”(W) × 10.5”(D) ATX/SSI CEB compliant MB |
| Drive Bay: |
External |
5.25" |
4 |
| 3.5" |
1 |
| Internal |
3.5" HDD |
1 |
| Temperature: |
0°C (32°F)~50°C (122°F) |
| Humidity: |
5%~95% non-condensing |
| Gross Weight: |
13kgs / 28.6lbs (w/o PSU & Rail) |
| Package Dimension: |
(W × D × H) mm: 579 × 761 × 242 mm |
| Mounting Options: |
CLM-882054B: 20" Slinding Rails + Bracket
CLM-882054B-26: 26" Slinding Rails + Bracket
GNS-1234RMK: 1234U rear mounting kit, 300mm depth |
| Backplane Module Options |
SNT-1041SS: 4×2.5" SAS & SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-1060SATA: 6×2.5" SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-2131SS: 3×2.5/3.5" SAS & SATA HDD/SSD in 2×5.25" Bay, hot swappable. |
