Image for display purposes only

Model: IPC C2EH 2U Chassis Only

is a H-series 2U 12-bay SAS/SATA storage server chassis, with rear hot-swappable OS drive option. This environmentally friendly solution features high-efficiency power supply, 3x easy-swap middle fans, SPGC pre-plated steel with minimal paint, and tool-less ball-bearing mounting rail, offering a cost-effective solution ideally suited for a broad range of applications.
Specifications

Model: IPC C2EH
Industry Standard: EIA-RS310D
Materials: Heavy-duty preplated SPGC cold-rolled steel
Finish: Front Panel : Texture-coated
Dimensions
(W × D × H)
mm: 482.6 × 700 × 88.8
inches: 19 × 27.5 × 3.5
Cooling: 3 × 80 × 38mm easy-swap fans
Power Supply: 800W EPS 80+
Expansion: 3 × PCI slots via riser card(full height, full length) or 7 × low profile PCI slots
Controls: Power on/off and system reset
Indicators: Power, 2 × LAN and HDD LEDs
System Board: 12”(W) × 13”(D) E-ATX/SSI EEB 3.6 compliant MB
Drive Bay: 12 × 3.5" external hot-swap drive bay plus:
1 × 3.5" interval HDD bay or 2 × 2.5" internal HDD bay or
2 × 2.5" external hot-swap drive bay (optional)
Temperature: 0°C (32°F)~50°C (122°F)
Humidity: 5%~95% non-condensing
Gross Weight: 18kgs / 39.6lbs (w/o PSU & Rail)
Mounting Options: 28” inner rail, 26” outer rail, tool-less
More Information: IPC C2EH Datasheet
