Products
|
DLD5500-L
55" TFT LCD, 2500 nits LED backlight, 1920x1080
- 55" sunlight readable, high brightness (2,500 nits)
- Resolutions: 1920 x 1080
- Wide viewing angle of 178° (H), 178° (V)
- LCD blacking detect free (H Tni 110°C)
- High contrast ratio (1000:1)
- Low power consumption
- BL MTBF: 100,000 hours
|
|
Specifications
| Model name |
DLD5500-L |
| Description |
55" TFT LCD, 2500 nits LED backlight, 1920x1080 |
| Size |
55" |
| Display area (mm) |
1209.6(H) x 680.4(V) |
| Brightness |
2500 cd/m² |
| Resolution |
1920x1080 |
| Aspect ratio |
16:9 |
| Contrast ratio |
1000:1 |
| Pixel pitch (mm) |
0.63 (H) x 0.63 (V) |
| Pixel per inch (PPI) |
40 |
| Viewing angle |
178° (H), 178° (V) |
| Color saturation (NTSC) |
75% |
| Display colors |
16.7M |
| Response time (Typical) |
9ms |
| Video interface |
VGA, DVI-D, HDMI, DP |
| Input power |
AC 100~240V |
| Power consumption |
166.8w |
| Dimensions (mm) |
1242.6 x 713.6 x 74.3 |
| Bezel size (U/B/L/R) |
15.3/15.3/15.3/15.3 |
| Weight (Net) |
36kg |
| Mounting |
VESA 400x200, 400x300 |
| OSD key |
4 keys (Power switch, menu, +, -) |
| OSD control |
Brightness, color, contrast, H/V position… etc |
| Operating temperature |
0°C ~ +50°C |
| Storage temperature |
-20°C ~ +60°C |
| Product approval |
CE, FCC |

|
|
|
