| Model |
CASO-25-NB |
| Dimensions (W × D × H) |
222 × 190 × 62 mm |
| Processor |
Intel® Atom Processor D2500 (Dual Core) 1.86GHz |
| Chipset |
Intel® NM10 Express Chipset |
| L2 Cache |
512 KB × 2 L2 Cashe |
| System Memory |
Single channel DDR3 1066/800 MHz
2 × DIMMs (ma × 4GB) |
| Graphics |
Integrated graphic VGA port & DVI
|
| Connectors (rear) |
1 × VGA / 1 × DVI
2 × LAN 10/100/1000MBit (Intel 82574L)
2 × COM RS232
2 × PS2
4 × USB2.0 |
| Audio |
Realtek High Definition Audio (ALC) Incl multi-stream support |
| Connectors (internal) |
1 × PCI
1 × Mini PCIe AUDIO (Front panel) AUDIO (SPDIF)
3 × USB
2 × SATA (3GBs)
2 × COM (Serial)
1 × LVDS 24 bit |
| Power Supply |
12V DC-IN power supply (60W / 80W) |
