Case |
Panel Material |
Aluminum |
Color |
Option |
Coating Requirement |
Spray Paint + Anode |
Cooling Mode |
Fan less Fully sealed design |
System Specification |
Form Factor |
uTX |
Processor |
INTEL® Braswell-D J3160 2.24GHz/QC |
GPU |
INTEL® HD Graphics 400 |
System Chipset |
INTEL® Braswell-D J3160 (SOC) |
System Memory |
4G/DDR3L |
BIOS |
64MB SPI Flash ROM |
Ethernet |
2*Realtek® RTL8111G Gigabit LAN |
Audio |
Realtek® ALC662 HD Audio |
Storage |
1* M-SATA connector |
WIFI Module |
Option |
Optical Device |
N/A |
Expansion |
2*PCI-E mini card for WLAN |
Display Output |
1*DP+2*HDMI |
Display |
Three Independent Displays |
Resolution |
3840x2160@ 30Hz、2560x1600@60Hz |
I.O Port |
3*USB3.0、1*Line-out、1*MIC、2*RJ45、1*Power Button、1*DC-Jack |
Power Adapter |
DC-IN (9~24V) |
OS Support |
Windows 7/8.1/10 |
Temperature |
Operating：-10 ~ +60℃ |
Humidity |
20%~90% (non condensing) |
Dimension |
148.0mm*116.0mm*25.0mm |
Certification |
FCC CE (Option) |
