Dimension (W*H*D)

– 185 * 142 * 60  mm

Construction

– Aluminum housing

Colors

– Black

Model Name

– JBC382F632-6200U-B (i5-6200U)
– JBC382F632-6300U-B (i5-6300U)

M/B model

– JNF632-6200U / JNF632E-6200U
– JNF632-6300U / JNF632E-6300U

CPU

– Intel® Skylake-U(i5-6200U /i5-6300U),TDP: 15W

BIOS

– AMI 128Mb Flash ROM

Memory

– 2 * SO-DIMM DDR4 Slot (Max. 32GB)

Storage Space

– 1 * 2.5” SATA Device
– 1 * m-SATA SSD Device (Mini PCIe)

Front I/O Port

– 2 * USB 2.0
– 2 * COM
– 1 * MIC , 1 * Line out

Rear I/O Port

– 2 * USB 2.0 , 4 * USB 3.0
– 1 * DP (max resolution:4096 x 2304@60Hz)
– 1 * HDMI (max resolution:4096 x 2160@24Hz)
– 2 * RJ45 (Intel Gigabit LAN)
– 1 * Line out
– WiFi (optional / JBC382F632W-6X00U-B)

Expansion Interface

– Mini PCIe # 1 : Half-size (for mini PCIe module)
– Mini PCIe # 2 : Full-size (shared with mSATA)

Power Source

– 12V DC-in Jack
– Adapter : AC_90~240V / DC_12V_5A / 60W

Certification

– EMC : CE , FCC
– Safety : RoHS , ErP

Environment

– Operating Temperature : 0 ~ 50℃
– Storage Temperature : -20 ~ 70℃

Mounting

-Wallmounting Kits

Packing

– Net Weight：2.2KG
– Gross Weight：3.5KG
– Color Box Dimension：250(W) x 118 (D) x 295 (H) mm

Warranty

–2 Year limited warranty
